Sale!

Simrad HD Digital Radar TXL-10S-6, At Price Of 5055.64 €

Simrad HD Digital Radar TXL-10S-6, At Price Of 5055.64 € - Image 2

Simrad HD Digital Radar TXL-10S-6, At Price Of 5055.64 € - Image 3

Simrad HD Digital Radar TXL-10S-6, At Price Of 5055.64 € - Image 4

Simrad HD Digital Radar TXL-10S-6, At Price Of 5055.64 €

Name: Simrad HD Digital Radar TXL-10S-6, At Price Of 5055.64 €
SKU: DM9IB 128366508
Availability: InStock

Original price was: $308.00.Current price is: $97.99.

Max Range, scale

Beam width

Rotation speed

Supply Voltage

Consumption

Max Wind Speed

Weight

Diameter

Size

Recommended Fuse Rating

Radar Modes

Interface

Radar Technology

Warranty

Clear

SKU: DM9IB 128366508 Categories: Electronics, Radars

Multiple payment methods, 100% payment security
Made of environmentally friendly materials
Safe Transactions, Always
Safe Shopping Guaranteed

The large HD radar range of 72 nautical miles is a great choice not only for coastal fishing and sailing, but also for longer walks at sea, especially in combination with a beamwidth of 1.2 ° horizontally and 2.0 ° vertically. The compact pedestal of the TXL-10S-6 and the high-performance 6-foot scanner are the perfect solution for sport fishing boats or motor boats with limited space.

You can move and maneuver seamlessly and safely in all conditions, thanks to the detailed information presented, the uncompromising detection of small or distant targets, the clear picture and the minimization of chaos on the screen, the so-called Screen-Clutter. With a power of 10 kW, Simrad HD Digital Radar withstands prolonged wind loads at speeds up to 100 knots, has a magnetron with a long life and a brushless motor for maximum longevity.

Additional features for the TXL-10S-6:

183cm, Open-array antenna with slim pedestal design
Meets IMO IEC62388 Annex D targeting specifications (triggers RACONs and SARTs at 5 NM ranges)
Automatic settings for Tune, Gain, and Sea Clutter in Harbor and Offshore modes
Dual EBL / VRM with alarm for incoming and pre-existing targets, regardless of mode
TrueColor display for improved goal differentiation
Radar overlay of charts (Heading sensor required)
MARPA Target Tracking technology (Heading sensor required)
Ability to control via tablet (iPad / Android) with optional Go Free wireless module
Ethernet connectivity compatible with all devices in the Simrad NSE / NSS / NSO series

Max Range, scale	72 NM (nautical miles)
Beam width	1.2° H +/-10% (6ft, -3dB width), 20° V +20% (4/6ft, -3dB width)
Rotation speed	27 RPM (4/6ft, Min 20 RPM at Max 100 Knots)
Supply Voltage	21.6 – 31.2 VDC (24V systems)
Consumption	230W (Max.) in maximum wind velocity
Max Wind Speed	100 knots (51 m/s)
Weight	36.0 kg
Diameter	1910 mm (75.2")
Size	461 x 457.4 x 260 mm (18.15” x 18.01” x 10.24”)
Recommended Fuse Rating	3A
Radar Modes	Head Up, North Up
Interface	HDS Live, HDS Carbon, Elite FS, Simrad NSS, NSO
Radar Technology	Pulse
Warranty	2 years
